Linkker LM312

From SgWiki
Jump to navigation Jump to search
SBS Transit SG3088R (Off Service)

Specifications[edit]

Operator(s) SBS Transit SMRT Buses
Registration no. SG3070R – SG3072K
SG3078U – SG3082G
SG3088R
SG3089M
SG3073H – SG3077Y
SG3083D – SG3087T
Vehicle make Linkker
Vehicle manufacturer
Vehicle model LM312
Vehicle bodywork Linkker LinkLight
Vehicle bodywork assembler Gemilang Coachwork
Length 12m
Width 2.55m
Quantity 10 10
20 (Total)
Year 2019
Period of registration 13 Jul 2021 – 13 Aug 2021
Passenger capacity Seating: 28
Standing: 55
Wheelchair bay: 2
Total: 83
Electric motor model Danfoss Editron EM-PMI375-T800-1600
permanent magnet assisted synchronous reluctance motor (dual inverter)
Battery Lithium iron phosphate
Battery capacity 177.5 kWh
Power/torque 139 kW / 828 Nm (Continuous)
231 kW / 2100 Nm (Maximum)
Suspension system Electronically Controlled Air Suspension (ECAS)
Braking system Anti-Lock Braking System (ABS)
Anti-Slip Regulation (ASR)
Air-con model Eberspächer Sütrak AC136 G4 AE
EDS model Mobitec MobiLED Ultima (Branded as Gorba imotion LED.e-advanced)
EDS controller model Gorba imotion CU.basic
PIDS model LAWO INFOtainment (Branded as Gorba imotion TFT.compact)
APCS model TNT Surveillance T-APC
Seat model Vogel Industrie System 750/3
Door model Masats
Additional features USB charging ports
TNT Surveillance Forward and Side collision warning system
TNT Surveillance T-FA Front Alert Camera
TNT Surveillance T-SA Side Alert Cameras
Stroller restraint system
Rooftop charging rails for inverted pantograph charging (Oppcharge)

Deployments[edit]

SBS Transit[edit]

Registration no. Service Advertisement
SG3070R BNDEP 38 NS & OS: Land Transport Authority (LTA): Eco Bus. Zero Emissions, Cleaner Air.
SG3071M BNDEP 38
SG3072K BNDEP 40
SG3078U BNDEP 38
SG3079S BNDEP 38
SG3080L BNDEP 38
SG3081J BNDEP 40
SG3082G BNDEP 38
SG3088R BNDEP 40 PA: Land Transport Authority (LTA): Eco-Friendly Electric Bus. 100% Cleaner Energy.
NS & OS: Land Transport Authority (LTA): Eco Bus. Zero Emissions, Cleaner Air.
SG3089M BNDEP 38 NS & OS: Land Transport Authority (LTA): Eco Bus. Zero Emissions, Cleaner Air.

SMRT Buses[edit]

Registration no. Service Advertisement
SG3073H KJDEP 976 NS & OS: Land Transport Authority (LTA): Eco Bus. Zero Emissions, Cleaner Air.
SG3074E KJDEP 976
SG3075C KJDEP 976
SG3076A KJDEP 976
SG3077Y KJDEP 976
SG3083D KJDEP 176
SG3084B KJDEP 176
SG3085Z KJDEP 176 PA: Land Transport Authority (LTA): Eco-Friendly Electric Bus. 100% Cleaner Energy.
NS & OS: Land Transport Authority (LTA): Eco Bus. Zero Emissions, Cleaner Air.
SG3086X KJDEP 176
SG3087T KJDEP 176 NS & OS: Land Transport Authority (LTA): Eco Bus. Zero Emissions, Cleaner Air.

Former deployments[edit]

Other information[edit]

Legend[edit]

Deployments
BNDEP Bedok North Depot
KJDEP Kranji Depot
Advertisement
PA: Ad covering partial sides on nearside & offside only, rest of body left unwrapped (in previous body colour).
NS: Window ad on nearside / left side.
OS: Window ad on offside / right side.

Buses in depots[edit]

SBS Transit[edit]

Click to expand/collapse
BNDEP 10 buses SG3070R SG3071M SG3072K SG3078U SG3079S SG3080L SG3081J SG3082G SG3088R SG3089M

SMRT Buses[edit]

Click to expand/collapse
KJDEP 10 buses SG3073H SG3074E SG3075C SG3076A SG3077Y SG3083D SG3084B SG3085Z SG3086X SG3087T

Type of purchase(s)[edit]

All buses are bought under Land Transport Authority (LTA)'s Bus Contracting Model (BCM).
